Aviation Parts AD7606BSTZ Digital Converters Pitch 0.100" (2.54mm)

  • 1
  • 2

Model Number : AD7606BSTZ

MOQ : 1 pcs

Payment Terms : L/C, T/T

Price : Negotiable

Packaging Details : boxes

Pitch : 0.100" (2.54mm)

Number of Rows : 200 kS/s

SNR - Signal to Noise Ratio : 95.5 dB

Operating Temperature : - 40 C

Maximum Operating Temperature : + 85 C

DNL - Differential Nonlinearity : +/- 0.99 LSB

Gain Error : +/- 32 LSB

INL - Integral Nonlinearity : +/- 2 LSB

Input Voltage : +/- 5 V/+/- 10 V

Contact Now

Aviation Parts AD7606BSTZ Digital Converters Pitch 0.100" (2.54mm)

Descriptions of Aviation Parts:

8/6/4 simultaneously sampled inputs True bipolar analog input ranges: ±10 V, ±5 V Pin to pin compatible with the state-of-the-art AD7606B Single 5 V analog supply and 2.3 V to 5 V VDRIVE

Fully integrated data acquisition solution

  • Analog input clamp protection
  • Input buffer with 1 MΩ analog input impedance
  • Second-order antialiasing analog filter
  • On-chip accurate reference and reference buffer
  • 16-bit ADC with 200 kSPS on all channels
  • Oversampling capability with digital filter

Flexible parallel/serial interface

  • SPI/QSPI™/MICROWIRE™/DSP compatible

Features of Aviation Parts:

  • 7 kV ESD rating on analog input channels
  • 95.5 dB SNR, −107 dB THD ±0.5 LSB INL,
  • ±0.5 LSB DNL Low power: 100 mW Standby mode: 25 mW
  • Temperature range: −40°C to +85°C
  • 64-lead LQFP package

Specifications of Aviation Parts:

Product Attribute Attribute Value
Product Category: Analog to Digital Converters - ADC
RoHS: Details
Series: AD7606
Mounting Style: SMD/SMT
Package / Case: LQFP-64
Resolution: 16 bit
Number of Channels: 8 Channel
Interface Type: Parallel, SPI
Sampling Rate: 200 kS/s
Input Type: Single-Ended
Architecture: SAR
SNR - Signal to Noise Ratio: 95.5 dB
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Packaging: Tray
Development Kit: EVAL-AD7606EDZ
DNL - Differential Nonlinearity: +/- 0.99 LSB
Gain Error: +/- 32 LSB
Height: 1.4 mm
INL - Integral Nonlinearity: +/- 2 LSB
Input Voltage: +/- 5 V/+/- 10 V
Length: 10 mm
Moisture Sensitive: Yes
Number of ADC Inputs: 8 Input
Number of Converters: 1 Converter
Operating Supply Voltage: 5 V
Pd - Power Dissipation: 142 mW
Power Consumption: 100 mW
Reference Type: External, Internal
Sample and Hold: Yes
Factory Pack Quantity: 160
Subcategory: Data Converter ICs
Supply Voltage - Max: 5 V
Supply Voltage - Min: 5 V
Type: S/H ADC
Width: 10 mm
Unit Weight: 0.028219 oz
